Pulse Fitness UK · Cardiovascular
Club Line Upright Cycle
Standard
The new ( 239H ) Upright Cycle is a compact, commercial-grade, heavy-duty stationary exercise cycle. Designed for high-traffic environments like gyms, health clubs, and rehabilitation centres. This cycle is built with professional-grade materials to withstand continuous daily use. Delivering a a smooth and comfortable, natural workout in self or powered options. Two Console choices are available with options for entertainment,...
4 variations
Connectivity
Specification sheet, lead time and installation scope on request.
Overview
- Category
- Cardio · Bikes
- Supplied by
- Equipt, with installation and service
Specification80
- Length
- 118cm / 46-7/16″
- Height
- 150cm / 59-1/16″
- Width
- 69cm / 27-3/16″
- Step-up height
- 18.6cm / 7-5/16″
- Weight
- 65kg / 143.3lbs.
- Maximum User Weight
- 150kg / 330.7lbs.
- Smartphone compatible charging
- Yes: 5V/1A (Compliant with BC1.2 USB battery charging protocol)
- iPod® / MP3, Audio in
- Yes
- Content Mirroring
- Yes: Supports iOS/Android Smartphones
- Touchscreen
- 39.7cm / 15.6″ Multi-Point Capacitive Touch; 1920 x 1080 Resolution
- Interactive User Console (cm/”)
- Yes: 50.6cm / 19-15/16″
- Navigation
- Touchscreen (& tactile controls, on the product)
- LAN (Ethernet)
- Yes
- WiFi
- Yes
- Bluetooth®
- Yes: FTMS protocol & BT/BLE
- USB
- Service Port, For software updates & Smartphone device charging
- Headphone Jack
- Yes
- Apps
- Yes: ZWIFT & Kinomap. Compatible for expanding implement of third party Apps
- Console O/S
- Android 10
- Speakers
- Yes: x2, 10W Audio Output
- Reading Rack
- Yes
- Personal Fan
- Yes: x2
- Telemetry
- Yes: Equipped for heart rate telemetry reading using a Wireless Heart Rate chest strap that supports BLE or standard 5kHz coded transmission ( Optional, chest strap required)
- HandPulse Sensors
- Yes
- Power requirements
- 12V (Lithium batteries located in Console)
- Mouldings
- The console is surrounded by an injection-moulded casing, these are durable, high impact thermoplastic housings, which seal internal components, protecting the vital parts against dust and sweat, and are easy to wipe clean.
- Programs
- 21 in Total (Hill Mode, Interval Mode, Goal Mode (Time, Distance, Calories), Virtual Reality Mode, Heart Rate Control 1/2 Mode, Fitness Test Mode, User 1/User 2 Mode)
- Manual
- Quick Start
- Hill
- Gradient training which imitates riding uphill and downhill, by automatically adjusting the Cycle’s resistance.
- Interval
- This workout offers both high, and low; levels of exertion. Producing greater endurance, by reducing a users oxygen level; then delivering a recovery period.
- Goal
- Set a Workout by Duration, Time, Distance & or Calories.
- Fitness Test
- Program is calculated based on a users heart rate.
- Heart Rate Programs
- The two Heart Rate Programs are intended to be used with a Wireless Chest Band (Heart Rate Transmitter). HRC1 (60% of MHR) is a moderate heart rate workout that targets Fat Loss. HRC2 (80% of MHR) is a higher heart rate workout that targets Improved cardiovascular function.
- Virtual Reality
- Pre-recorded workout walks/runs of famous landscapes, captured from various locations around the world.
- User-Defined Programs
- Two programmable User-Defined Programs are available. Users can control Quick Start, Speed, Age, Weight and Workout Time.
- Social Media & Multimedia
- Yes: Installation of integrated apps/weblinks (NETFLIX, Disney+, YouTube™, Prime Video, Spotify, Chrome™, Facebook®, CNN, Threads, Instagram)
- Units
- Metric / Imperial (Switchable)
- Level
- 36
- Energy
- Mets
- Power
- Watts
- Time
- Minutes & Seconds
- Calories
- Kcals
- Distance
- Km / miles
- Heart rate
- bpm
- Speed
- kph / mph, rpm
- Languages available
- English (US), German, Israel, Italian, Portugal, Russian, Saudi Arabia, Simplified Chinese & Spanish
- One-button Start
- Yes
- Quick Controls
- Yes
- Display
- Adjust Default Brightness, Configuration
- Audio
- Adjust Default Headphones Volume, Configuration
- Ethernet
- Configure
- Wi-Fi
- Configure
- Service & Firmware
- Automatic Software Updates (OTA); Manual Updates (USB)
- HDMI
- HDMI Input
- Apps
- Apps Update
- Screensaver Setup (Publicity)
- Add Images, Add Videos
- Resistance System (Power)
- Electromagnetic Braking System (EMS)
- Drive
- 8 Rib Poly-V belt, two step drive (Manufactured in Germany)
- Resistance (Max.)
- 280W Max.
- Flywheel
- 10kg / 22lbs.
- UK/EU
- 12V (Lithium batteries located in Console)
- ‘Quick’ controls featuring handlebar resistance adjustments
- Yes
- Resistance Levels
- 36
- Easy adjust pedal strap
- Yes
- Multi-position handlebars with elbow support
- Yes
- Comfort contour seat
- Yes
- Single-handed seat adjustment
- Yes
- Storage bucket/cup holder
- Yes: There is provision for a users personal storage. The storage bucket has enough room to deposit items like mobile phones, keys & even a water bottle
- Front wheels for easy mobility
- Yes
- Frame Construction
- All Pulse Fitness products are constructed from durable 3mm (11 gauge) steel that is designed to give exceptional structural integrity and stability even during the most vigorous workout.
- Frame Protection
- Once welded, the frames are treated against corrosion by being grit blasted and zinc pre-treated (for guaranteed durability). They are furnace baked, heat-cured and electrostatically epoxy powdered (which ensures maximum adhesion). This gives them a tough, corrosive-resistant and easy to clean finish, offering unbeatable reliability and longevity.
- Smooth Operation
- Pulse Fitness cardiovascular products are renowned for their smoothness of operation. This results from our precision-engineered manufacturing processes.
- Hand-Grip Assembly
- The hand-grips are formed from a slip-resistant, extruded rubber compound that is non-absorbing and wear-and-tear resistant.
- Mouldings
- The injection-mouldings are durable, high impact thermoplastic housings, which seal internal components, protecting the vital parts against dust and sweat, and are easy to wipe clean.; All rubber coverings are durable and have a high impact resistance; they too, are easy to wipe clean.
- Seat
- The long-lasting, easy-to-clean, ergonomically designed saddle seat with comfort groove has a high resistance to: abrasion, ageing, bacteria, disinfectant, mildew, oil and stains. It is puncture and wear resistant.
- Multipurpose Handlebars
- Yes: Perimeter
- Moulded Rubber Foot Pads
- Yes: Designed to protect polished floors whilst enhancing safety. Moulded rubber foot pads are supplied as standard.
- Key Features (USP’s)
- Full-Body Engagement: The upright posture engages the core, back, and upper body muscles (biceps and triceps) for stability.; 15.6″ Touchscreen Console; 21 Programmes / 36 Effort Levels; Entertainment (apps); Virtual interactive video workouts; Internet Connection (Ethernet/Wi-Fi); Bluetooth® Connectivity (Headphones/Heart Rate Monitoring); Content Mirroring; Seamless automatic Software updates; Poly V-belt combination ensures quiet operation; Low step over height; Adjustable self-levelling Pedals; Comfortable contoured seat; Elbow support mouldings; Integrated personal storage
- Back-order Details
- Currently, delivery estimate, 8 weeks from receipt of order
- Model No
- 239H
Options1
Configuration
StandardInclusive IFI
